Brushless Direct Current Motor Stator Winding Machine By Wire Nozzles

Brushless Direct Current Motor Stator Winding Machine By Wire Nozzles

    • Brushless Direct Current Motor Stator Winding Machine By Wire Nozzles
    • Brushless Direct Current Motor Stator Winding Machine By Wire Nozzles
  • Brushless Direct Current Motor Stator Winding Machine By Wire Nozzles

    Product Details:

    Place of Origin: China
    Brand Name: SMT
    Certification: ISO / SGS / BV
    Model Number: NR1807

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 Set
    Price: Price unit: USD; Price can be negotiated as per customer requirement.
    Packaging Details: Plastic stretching film, vacuum package, plywood cases. The dimension depends on actual machine size.
    Delivery Time: About 50 days after downpayment
    Payment Terms: T/T, L/C
    Supply Ability: About 15 Set/Sets per Month
    Contact Now
    Detailed Product Description
    Name: Brushless Direct Current Motor Winding Machine Winding By Wire Nozzles Model: SMT-NR1807
    Station: One Working Station Needle No.: Can Be 3 Winding Needles
    Stack OD: Max180mm Warranty: One Year

    Brushless Direct Current Motor Winding Machine Winding by Wire Nozzles  SMT-NR1807


    Can be equipped with 3 needle (Tungsten steel wire nozzle) for winding together, just one station with outer ring protection. It can achieve auto wire hooking, cutting, arraying and winding on stators directly.

    (1) Technical Parameters



    Model SMT-NR1807
    Needle number 1~3 needles
    Stator OD ≤Φ180mm
    Stator ID ≥Φ40mm
    Stator stack height ≤110mm with plastic frame
    Wire diameter range Φ0.2~Φ1.2 mm
    Load winding speed ≤600 r/min
    Winding precision ±0 turn
    Power 5.5Kw
    Weight 1250Kg
    Dimension (L)760×(W)1250×(H)2350mm



    (2) Brief Instruction of Machine

    Machine "Brushless Direct Current Motor Winding Machine Winding by Wire Nozzles" is used for winding electric wires on BLDC stators automatically and directly.

    (3) Main Specifications



    1. The machine is suitable for brushless DC in-slot converter motors in the field of automobile, household appliance and air etc., like servo motor, fan motor, washing machine motor, compressor motor and stepper motor, etc.;

    2. CNC controls servo motor to achieve high-speed running and precious location;

    3. It can achieve auto winding, arraying, indexing, hooking and cutting, fault diagnosis function and so on.

    Brushless Direct Current Motor Stator Winding Machine By Wire Nozzles


    (4) Services


    Combining years of experience, we can provide high-qualified machines which are simple operated and easy for maintenance, including single set machine or whole production line machines.

    Before placing an order, we can have a technical discussion if customers have any doubt. And if customers have any requirement in design or allocation, we also will try our best to satisfy them.

    Besides, our warranty time is one year and during this period, we’ll offer some spare parts for free if they’re broken due to quality issue or design issue. Before delivery, we’ll also offer some wearing parts for free.

    When customers have some problems with the machine, inform us and our after-sales engineers will be in customer’s site in the shortest time.

    (5) Application of SMT Machines

    SMT machines can finish slot insulation insertion, coil winding, inserting, forming and lacing automatically, which are suitable for various motors of new energy automobile, generator, garden tools, fans, exhaust fan, compressor, water pump and deep well pump, household appliance, reducer, BLDC motor and so on.

    (6) Company Profile - Suzhou Smart motor Equipment Manufacturing Co., Ltd.



    Suzhou Smart Motor Equipment Manufacturing Co., Ltd. is located in Suzhou, a commercial and tourist city in Yangtze River Delta, which is convenient for our foreign trade.

    We SMT are the manufacturer of motor production machines, like Winding Machine, Coil Inserting Machine and so on.

    Since established in year 2010, we began to provide customers with high-qualified products, excellent after-sales service and professional technical support. And we expanded our company site from 800 square meters to 5000 square meters within one year. From that time on, we began to do foreign trade by ourselves and keep developing the foreign market.

    Until now, we have many customers like SEW, ABB, Siemens, WEG, REGAL, HITACHI, EMERSON and YILMAZ etc. from different countries.
