|Name:||Single Phase Motor Automatic Stator Coil Lacing Machine||Model:||SMT-DW350|
|Stack Height:||100 - 260mm||Power Supply:||380v/50/60Hz 0.75kw|
|Automatic Grade:||Semi Automatic||Lacing Power:||Servo Motor|
Fan / Washing Machine Stator Winding Machine SMT - DW350 60Hz 0.75kw
This machine is used to inserting coil and wedge into stator. And it can insert coil and wedge simultaneously. This HMI can set all the necessary data. With easy and convenient tooling change process, this machine is suitable for three phase motor, fan motor and other motor, with a veriety model number but low output.
Wedge fedding mode can be set according to different motor.Horizontal Winding Inserting Machine is equipped with human-machine control interface, It has the characteristic of widely application, high automation, easy operation and convenient tooling change.
(1) Main Technical Description
|Overhang coils height||20-85mm|
|Lacing Speed||about 0.7s/s|
|Power Supply||380V/50/60Hz 7Kw|
|MOQ||1 set Single Side Lacing Machine|
This machine adopts servo driven system, CNC control design and HIM program.
The indexing is driven by servo system. Different lacing mode could be set such as slot lacing, interval lacing, and fancy lacing.
Main spindle adopts servo control system. The rotation speed can be set.
Two needles driven by servo system lace upper and lower coil simultaneously.
Machine can automatically feed thread and cut thread. There is no need to tie a knot.
Tooling change is fast and convenient. Stator stack length range is 50-130mm.
Lacing tension can be set,
Production capacity ≤1s/slot.
Should be no copper wire snap and wire enamel broken.
Primary qualification rate ≥98.5%, after rework, the rate ≥99.5%
his machine adopts safety grating protection system. Operator need to stand when operating.
Machine adopts two hands simultaneously start button to ensure safety.
(3) Machine Main Characteristic
1. Adapting industrial PLC, human-computer interface and horizontal frame-structure design, the servo system machine accurately controls the lacing action.
2. Different lacing methods such as slot-by-slot lacing, interval lacing and fancy lacing are programmable.
3. This machine is suitable for the big stator with high winding over-hang.
4. The tooling is movable and convenient for stator fast loading and unloading, hence to reduce the labor strength effectively.
