Automatic Inserting And Drifting Machine , Stator Coils Shape Expanding and Forming Machine

Automatic Inserting And Drifting Machine , Stator Coils Shape Expanding and Forming Machine

  • High Light

    automatic motor winding machine

    ,

    induction motor winding machine

  • Name
    Automatic Stator Coils Shape Expanding And Forming Machine
  • Stator I.D
    Dia 20~100
  • Stator .O.D
    Max 160mm
  • Core Length
    Max 120mm
  • Tooling Travel
    Max 70mm
  • Appropriate Wire
    Copper Wire And Aluminum Wire
  • Slot Number Range
    8~48 Slot
  • Power Supply
    380V/50/60HZ 3KW
  • Place of Origin
    China
  • Brand Name
    SMT
  • Certification
    ISO/SGS Audit
  • Model Number
    SMT-I
  • Minimum Order Quantity
    1
  • Price
    Negotiable
  • Packaging Details
    Plastic warpped ,vacuum Packed in plywood case
  • Delivery Time
    30-50 days
  • Payment Terms
    L/C T/T
  • Supply Ability
    1 PCS

Automatic Inserting And Drifting Machine , Stator Coils Shape Expanding and Forming Machine

Electric Induction Motor Automatic Winding inserting Drift Forming System





This machine is suitable for big power stator, long stack length stator(deep-well pump stator) or other big dimension stator. It is horizontal type with a auto slider. Stator can be moved by lifting device. Tooling adopts flexible principles of inner expansion, outer wrapping and edge forming. It is controlled by PLC. The parameter can be set in the HMI.



1. Our Service:



Product Name Automatic Winding and Inserting Machine Application Electric motor stator production
Status New Paint On request
Warranty time One year after machine(s) arrive in customer’s plant Service Overseas service center available



2.Basic Parameters



1.Basic machine complete with controls, less tooling.
2.Heavy duty construction.
3.All electric and pneumatic - no hydraulics.
4.Machine enamel paint on request.
5.Allen Bradley Programmable Controller.
6.Compact design on wheels for ease of relocation and
operator convenience.
7.Maximum stack height up to 4 inches, 102mm, with rapid
adjust feature.
8.Four-station turntable.
9.Smooth precise sinusoidal turntable index.
10.Specification storage for use with the Windows compatible computer.



3.SOFTWARE FEATURES:
a) Specification storage of over 1,000 winding patterns.
b) One (1) minute specification change.
c) Upload/download to disk capability.
d) Machine diagnostics utilizing visual basic software and full access to servo software.
e) Machine functions independent of computer for reliability.
f) Easy menu access to all machine winding parameters.
g) Maintenance recording and access password protected.
h) Pre-programmed maintenance schedules with operator prompting.


11.Maximum flyer speed up to 3,500 RPM, fully closed loop and tied to coilform jump for crossover and turn count control.
12.Capable of variable speed, either step to step or slow to jump for ± 0 turn count.
13.Capable of pulling up to two (2) #19 AWG, 0.95mm, wires in parallel (may be different sizes.)
14.Variable wire tension control.
15.Includes wire feeds from machine to wire spools. Customer to specify either ceramic eyelets or spring lined plastic tubing.
16.Fully electronically adjustable turn count, coilform jump, upper tooling index, and lead length control from the computer specification routine.



4. About Us

Take full advantage of experienced engineers , skillful professional , perfect equipment , strict manufacturing process control and wide coverage service net-work , we are dedicated to provide our customers with the optimized solution to electric motor manufacturing , so far , except the big market share in China , we export our machines to the worldwide countries such as USA Italy , Australia , India , Brazil , Mexico ,Turkey , Tailand , Vietnam Iran etc,and our machines share the great the reputation among customers for its durable , reliable perormance , reasonable price and good after sales.
