Double Station Automatic Stator Winding Machine For High - Power Motor SMT - R350

Double Station Automatic Stator Winding Machine For High - Power Motor SMT - R350

  • Double Station Automatic Stator Winding Machine For High - Power Motor SMT - R350
  • Double Station Automatic Stator Winding Machine For High - Power Motor SMT - R350
Double Station Automatic Stator Winding Machine For High - Power Motor SMT - R350
Product Details:
Place of Origin: China
Brand Name: SMT
Certification: ISO9001/SGS/CE
Model Number: SMT-R350
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: Plywood Box for Your Machine.
Delivery Time: 33 - 57 days
Payment Terms: T/T, L/C, Western Union, D/A
Supply Ability: 1pcs / 30 - 57 days
Contact Now
Detailed Product Description
Name: Double - Station Winding Machine R350 For High - Power Motor Color: White
Non-Load Speed: ≤1500r/min Flier: 200mm
Transfer Number: 2-6pcs Power Supply: 220v/50/60Hz 7Kw
Weight: 900kg Dimension: (L)2000X(W)1450X1500mm
Winding Head: 2 Air Pressure: ≥0.6MPa
Transfer Distance: ≥170mm
High Light:

ceiling fan coil winding machine

,

ceiling fan winding machine

,

Double Station Stator Winding Machine

Double - station Automatic Stator Winding Machine R350 For High - Power Motor





(1) Main Technical Parameter



Model R350
Wire Diameter 0.3-1.2mm
Winding Diameter 100-350mm
Transfer distance ≤250mm
No-load speed 1500r/min
Power Supply 220V/50/60Hz 1.5Kw
Weight 900kgs
Dimension 2000*1450*1500mm
MOQ 1 Set Winding Machine
Delivery time 30 days after the order is confirmed



(2) Application:


1. Adopts PLC system and sets the procedures through the display screen, so to extremely strong the reliable operation of the whole machine.
2. Electric parts are designed in modularization, can reduce the maintenance cost.
3. The main driving operation uses the frequency-conversion speed adjustment mode, keeps the advantages of short driving chain, large startup torque, wide speed adjustment range, energy saving and low noise.
4. The winding distribution adopts the stepping motor and high-precision reduction gear.
5. It's can realize the continuous stepping stepless adjustment from 0.01mm, and bring the convenient adjustment, high distribution precision and large torque.
6. CNC winding transformer for cctv power distribution box has the machine tool wire storage automatic computation, automatic counting, automatic stop, stop memory and so on, simplifies the operation greatly.
7. It can realize the multi-wire multi-layer winding.

(3) Machine Main Function And Characteristic


Winding tooling: each machine has one set winding tooling and three vertical winding forms.
The whole set of tooling can be changed, and it takes about 15min.
The turntable is two stations structure. It adopts servo system to rotate and index transfer form.
Allow three wires winding simultaneously.
Main spindle is controlled by servo motor. The coil turn number accuracy is ±1 turn.
The working rotation speed can be set . Machine has no distinct vibration and noise.
Free of enamel damage and wire snap. Once the copper wire is run out, machine will automatically stop.
PLC can set turn number, winding speed, tooling sunk height, tooling sunk speed and winding direction.
X andY spindle of wire hooker and wire cutter adopts servo system. It can adjust the length of bridge wire and lead wire.
Tooling sunk adopts servo system. The max segment number of tooling sunk is 6.



(4) OEM/ODM Profile


Taking full advantage of experienced engineers, skillful professionals, perfect equipment, strict manufacturing process control and wide coverage service net-work, we are dedicated to provide our customers with the optimized solution to electric motor manufacturing. So far, except the big market share in China, we export out machines to the worldwide countries such as USA, Italy, Australia, India, Brazil, Mexico, Turkey, Thailand, Vietnam, Iran, etc, and our machines share the great reputation among customers for it durable, reliable performance, reasonable price and good after-service.



(5) Production Line



With good service, professional team and reliable quality, Nide provide customer with different kinds of AC motor, DC motor,BLDC motor manufacturing technical consulting service and Turn-key projecting service, including the motor cost evaluation, manufacturing know-how, staff training,and complete turn-key project.



(6) About Our Company



Located in Suzhou, a beautiful city of industry, commerce heart in Yangtze River Delta, Smart is specialized in the R&D, manufacturing and sales of induction motor machinery. Our machines produced in Suzhou factory are mainly applied to induction motors such as washing machine motor, air conditioner motor, pump motor, coil motor, three-phase motor, fan motor and compressor motor, etc.
