Name: Automatic Compressor Motor Stator Coil Final Forming Machine Model: ZZ160
Stator I.D.: 50-100mm Stator O.D.: ≤160mm
Machine Weight: About 700kg Machine Dimension (LxWxH): 650x 900 X 2300mm
High Light:

Pre - Forming Machine

,

electric motor winding equipment

Automatic Compressor Motor Stator Coil Final Forming Machine SMT - ZZ160





This machine is used for small to middle motor stator coil forming after coil insertion, could shape the stator end coil OD, ID and height approaching to required size via initial extruding, and good for the next coil lacing process,with single-tooth slot insulation protective device. It is driven by hydraulic system; PLC programming; whole schematic design of inner expansion, outer wrapping and edge forming ensures appropriate winding outside dimension. Machine has cuff supports and sliding table,which is convenient and safe for operation.
fully hydraulic system, industrial PLC design;
independent 3D forming;
fast fixture replacement for optional;
tact time≤15s/set;



(1) Main Technical Features



Model ZZ160
Stack height 16-100mm
Stator I.D 50-100mm
Stator O.D ≤160mm
Displacement of cylinder 20F
Input 380V/50/60Hz
Power supply 3.75kw
Machine weight About 700kg
Machine dimension (LxWxH) 650x 900 x 2300mm



(2) Application



The products are mainly applied in new energy automobile motor, servo motor, generator, three-phase motor, pump motor, compressor motor, household appliance motor and other induction motors. As a world leader, we have obvious advantages in stator and rotor core assembly, slot insulation, auto winding, auto inserting, auto fusing, auto resin impregnation and other motor production technology for different sizes and slot shape of stator.

Focusing on international trading, we have placed our priority on both product quality and service, which are the key elements that make your brand more competitive in the global market. If you are looking for machines, components, or OEM products, SMT motor Equipment will be your most reliable partner.

We are ready to establish a long business relationship with your esteemed company as a supplier, a partner and a friend. We warmly welcome you from worldwide.


(3) Machine Main Characteristic



This machine adopts whole hydraulic system and PCL program.

This machine can adjust the forming stack length by changing washer.

Both slot paper and wedge should not be damaged or turned over. The stator should not be deformation or stator lamination should not be upward. There is no wire enamel broken.

Production capacity ≤13s/set (exclude loading/unloading time)

Primary qualification rate ≥99.5%, after rework, the rate ≥99.9%

This machine adopts safety grating protection system. Operator need to stand when operating.

Machine adopts two hands simultaneously start button to ensure safety.
